Menowa is a swp-d cardan shaft supplier from china, wholesale and direct sales swp-d cardan shaft at a reasonable price.
SWP-D cardan shaft serves as a vital mechanical transmission part widely applied in heavy industrial mechanical systems. Featuring a practical split fork structure, this cardan shaft adopts well-matched universal joint components and sturdy shaft body to steadily transfer torque and rotational power between misaligned driving and driven equipment. It delivers stable running performance and good deformation resistance under complex working conditions with regular angular deflection and axial displacement during operation. The rational structural layout enables it to bear steady mechanical loads and maintain smooth power transmission for long-term continuous operation. It fits perfectly for steel rolling equipment, industrial processing machinery and other heavy-duty mechanical scenarios, bringing stable transmission support for daily industrial production and mechanical operation with reliable practical performance and simple daily maintenance needs.

| Model | Rotary Diameter D mm | Nominal Torque Tn kN ·m | Pulsating Fatigue Torque Tp kN ·m | Alternating Fatigue Torque Tf kN ·m | Axis Angle β (°) | Size / mm | Rotational Inertia kg ·m2 | Quality kg | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Lmin | D1 | D2 (H7) | D3 | E | E1 | bxh | h1 | L1 | Nxd | Lmin mm | Increase 100mm | Lmin mm | Increase 100mm | ||||||
| SWP160D | 160 | 20 | 14 | 10 | ≤15 | 450 | 140 | 95 | 121 | 15 | 4 | 20×12 | 6 | 90 | 6×φ13 | 0.116 | 0.008 | 36 | 2.5 |
| SWP180D | 180 | 28 | 20 | 14 | ≤15 | 515 | 155 | 105 | 127 | 15 | 4 | 24×14 | 7 | 105 | 6×φ15 | 0.211 | 0.012 | 52 | 3.4 |
| SWP200D | 200 | 40 | 28 | 20 | ≤15 | 585 | 175 | 125 | 140 | 17 | 5 | 28×16 | 8 | 120 | 8×φ15 | 0.345 | 0.016 | 69 | 3.8 |
| SWP225D | 225 | 56 | 40 | 28 | ≤15 | 700 | 196 | 135 | 168 | 20 | 5 | 32×18 | 9 | 145 | 8×φ17 | 0.692 | 0.039 | 108 | 6.2 |
| SWP250D | 250 | 80 | 56 | 40 | ≤15 | 810 | 218 | 150 | 219 | 25 | 5 | 40×25 | 12.5 | 165 | 8×φ19 | 1.373 | 0.079 | 176 | 7.2 |
| SWP285D | 285 | 112 | 78 | 56 | ≤15 | 880 | 245 | 170 | 219 | 27 | 7 | 40×30 | 15 | 180 | 8×φ21 | 2.367 | 0.099 | 232 | 9.4 |
| SWP315D | 315 | 160 | 112 | 80 | ≤15 | 1000 | 280 | 185 | 273 | 32 | 7 | 40×30 | 15 | 205 | 10×φ23 | 3.993 | 0.219 | 322 | 12.8 |
| SWP350D | 350 | 224 | 157 | 112 | ≤15 | 1100 | 310 | 210 | 273 | 35 | 8 | 50×32 | 16 | 225 | 10×φ23 | 6.426 | 0.226 | 420 | 13.9 |
| SWP390D | 390 | 315 | 220 | 158 | ≤10 | 1100 | 345 | 235 | 273 | 40 | 8 | 70×36 | 18 | 215 | 10xφ25 | 9.690 | 0.303 | 510 | 21.1 |
| SWP435D | 435 | 450 | 315 | 225 | ≤10 | 1220 | 385 | 255 | 325 | 42 | 10 | 80×40 | 20 | 245 | 16×φ28 | 17.712 | 0.545 | 738 | 25.7 |
| SWP480D | 480 | 630 | 440 | 315 | ≤10 | 1400 | 425 | 275 | 351 | 47 | 12 | 90×45 | 22.5 | 275 | 16×φ31 | 29.088 | 0.755 | 1010 | 30.7 |
| SWP550D | 550 | 900 | 630 | 450 | ≤10 | 1520 | 492 | 320 | 426 | 50 | 12 | 100×45 | 22.5 | 305 | 16×φ31 | 55.252 | 1.435 | 1454 | 38.1 |
| SWP600D | 600 | 1250 | 875 | 625 | ≤10 | 1880 | 544 | 380 | 480 | 55 | 15 | 90×55 | 27.5 | 370 | 22×φ34 | 100.575 | 2.493 | 2235 | 53.2 |
| SWP650D | 650 | 1600 | 1120 | 800 | ≤10 | 2040 | 585 | 390 | 500 | 60 | 15 | 100×60 | 30 | 405 | 18×φ38 | 152.064 | 3.210 | 2880 | 65.1 |
